Laser Scanner Prism Reference Sphere (145mm Diameter)

Overview

The XXL FLEXI Laser Scanner Reference Sphere Set with 3 Spheres provides a robust and durable reference target solution for projects involving large objects, long scanning distances, and demanding field conditions. Each sphere features a 200 mm diameter, allowing visibility from greater distances than conventional reference spheres.

Manufactured in Germany, the XXL FLEXI spheres combine advanced materials, precision geometry, and impact-resistant construction to support both standard laser scanning workflows and high-precision measurement applications.

What Makes the FLEXI Reference Sphere Unique?

The XXL FLEXI reference spheres are engineered to deliver exceptional durability and measurement performance.

• Precise geometry suitable for laser scanning and high-precision applications such as structured light scanning.
• Specialized material construction designed for continuous professional use.
• Integrated shock absorber technology that absorbs impacts and returns to its original shape after a short period.
• Advanced surface coating that provides excellent reflection characteristics and long-term durability.
• Detachable magnetic mount for flexible deployment on metallic surfaces.

Product Features

• Set of 3 XXL FLEXI reference spheres
• Sphere diameter: Ø 200 mm
• Durable materials designed for daily use.
• Integrated shock absorber protects the surface from impact damage.
• Spherical geometry supports reliable detection from virtually all directions.
• Long special connection with M8 female thread.
• Compatible with mini prism for XXL reference spheres (Part No. 030-10226).
• Manufactured from a combination of plastics with a specialized surface coating.
• Optional compatibility with reference sphere adapters (Part No. 030-10171).
• Detachable magnetic mount for flexible positioning.
• Suitable for operation between -40°C and +75°C.
• Manufactured in Germany.

Transport and Storage

The set is supplied in a durable transport case designed to protect the spheres during transport and storage.

• Case dimensions: 575 × 470 × 270 mm
• Environmentally friendly case manufactured from recycled material.
• Custom-fit foam insert for secure storage and transport.

Applications and Use Cases

The XXL reference spheres are particularly effective for large-scale scanning projects where targets must remain visible from extended distances.

• Scanning of large objects and facilities.
• Long-range reference target positioning.
• Placement of reference spheres at significantly greater distances compared to conventional spheres.
• Linking point clouds to existing control networks using the compatible reference sphere adapter.
• Fast deployment on metallic surfaces using the magnetic mounting system.

Industries

• Architecture and heritage preservation
• Digital factory and plant engineering
• Mining and tunneling
• Energy and utility infrastructure
• Aircraft and shipbuilding
• Foundry and steel industry
• Chemical and process industries
• Forensics

Technical Highlights

• Quantity: 3 Reference Spheres
• Sphere Diameter: Ø 200 mm
• Connection Type: M8 female thread
• Magnetic Mount: Detachable
• Case Dimensions: 575 × 470 × 270 mm
• Operating Temperature: -40°C to +75°C
• Manufactured in Germany
